HPE 665243-B21 10Gb 2Port PCIe 560FLR-SFP+ Network Adapter for G8-G10

HPE 665243-B21 Dual Port 10Gb Ethernet 560FLR-SFP+ PCI Express 2.0 x8 Network Adapter for ProLiant Generation8 Generation9 Generation10 Servers (Brand New with 3 Years Warranty)

The HPE Ethernet 10Gb 2-port 560 FLR-SFP+ FlexibleLOM adapter features low cost, low power dual port PCIe v2.0 x8 lane adapter designed for use in HPE ProLiant Gen8 or higher Rack and scalable servers. The HPE 560FLR-SFP+ addresses the demanding needs of the next-generation data center by providing unmatched features for virtualization and scalability to keep up with the HPE ProLiant Gen8 or higher server platform, with the proven and reliable performance HPE customers have come to expect. The HPE 560FLR-SFP+ adapter enables connections with Direct Attach Copper cables as well as SR fiber optic modules. The HPE 560FLR-SFP+ supports high performance networking features such as VLAN tagging, low latency interrupts, TCP and UDP checksum offloading, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), WOL, and jumbo frames.

Dual-port 10 Gb Ethernet PCIe Gen 2.0, x8 Lane Adapter Designed for Maximum Network Performance.
20 Gb/s full duplex Ethernet transfer rate per port (40 Gb/s aggregate) with SFP+ cages allows use of Direct Attach copper and SR fiber optic modules. Intel Virtualization Technology for Connectivity (VT-c) with VMDq and SR-IOV supports VMware NetQueue and Microsoft VMQ helping to meet the performance demands of consolidated virtual workloads. Supports Wake-on-LAN (WOL) at 1Gb and has PXE , MSI-X support, Teaming, and IPv6. Adapter supports Hewlett Packard Enterprise Sea of Sensors 3D Technology.

The HPE 665243-B21 Ethernet 10Gb dual port 560FLR-SFP+ FlexibleLOM adapter features the latest generation 10 GbE Intel 82599 Controller. The HPE 560FLR-SFP+ is a low cost, low power dual port PCIe v2.0 x8 lane adapter designed for use in HPE ProLiant Gen8 or higher Rack and scalable servers. The HPE 560FLR-SFP+ addresses the demanding needs of the next-generation data center by providing unmatched features for virtualization, scalability to keep up with the HPE ProLiant Gen8 or higher server platform, with proven and reliable performance HPE customers have come to expect. The HPE 560FLR-SFP+ adapter enables connections with Direct Attach Copper cables as well as SR fiber optic modules. The HPE 560FLR-SFP+ supports high performance networking features such as VLAN tagging, Low latency interrupts, TCP and UDP checksum offloading, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), WOL, jumbo frames, PXE boot and virtualization features and is SR-IOV ready. This Dual Port Network Adapter comes with 3 Years Warranty.

Specifications

Brand: HPE
MPN: 665243-B21

Option Part Number: 665243-B21
Spare Part Number: 669281-001
Assembly Number: 665241-001

General

Device Type: Network Adapter
Form Factor: Plug-In Card
Interface (Bus) Type: PCI Express 2.0 x8

Networking

Ports: 10Gb Ethernet x 2
Connectivity Technology: Wired
Data Link Protocol: 10 GigE
Data Transfer Rate: 10 Gbps
Remote Management Protocol: SNMP
Status Indicators: Port status, link activity
Features: Wake on LAN (WOL), Jumbo Frames support, teaming support, PXE support, Large Send Offload (LSO), Receive Side Scaling (RSS), TCP Segmentation Offload (TSO)

Processor / Memory

Processor1: - Intel

Expansion & Connectivity

Interfaces: 2 x 10Gb Ethernet
Compatible Slots: 1 x FlexibleLOM

Miscellaneous

Compliant Standards: IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.1Qau, UL, BSMI, BSMI CNS 13438 Class A, ICES-003, EN55024, EN55022 Class A, WEEE, FCC Part 15 A, VCCI V-3 Class A ITE, EN 61000-3-2:2006, EN 61000-3-3:2008

Software / System Requirements

OS Required: SunSoft Solaris 10, SuSE Linux Enterprise Server 11, SuSE Linux Enterprise Server 10, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Microsoft Windows Server 2008 (32/64-bits), Red Hat Enterprise Linux 5.x, VMware ESXi 4.1, VMware ESXi 5, VMware ESX, Microsoft Windows Server 2008 R2 (32/64-bits), Microsoft Windows Server 2012 (32/64-bits)

Environmental Parameters

Min Operating Temperature: 32 °F
Max Operating Temperature: 131 °F
Humidity Range Operating: 10 - 90% (non-condensing)

Compatibility Information

Designed for

HPE Apollo: 4520 Gen9

HPE ProLiant DL Series: DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Entry, DL160 Gen8 Performance, DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL20 Gen9, DL20 Gen9 Entry, DL20 Gen9 Performance, DL20 Gen9 Solution, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Special Server, DL380 Gen9 High Performance, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL385p Gen8 Storage Centric, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, DL560 Gen9, DL560 Gen9 Base, DL560 Gen9 Entry, DL560 Gen9 Performance

HPE ProLiant SL Series: SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, SL250s Gen8 2U Left Half Width Tray, SL250s Gen8 2U PCIe Gen3 Left Tray, SL250s Gen8 2U PCIe Gen3 Right Tray, SL250s Gen8 2U Right Half Width Tray, SL250s Gen8 Base 2U Left Half Width Tray, SL250s Gen8 Base 2U Left Tray Server, SL250s Gen8 Base 2U Right Half Width Tray, SL250s Gen8 Base 2U Right Tray Server, SL270s Gen8 1U Left Half Width Tray, SL270s Gen8 1U Right Half Width Tray, SL270s Gen8 Base 4U Left Half Width Tray, SL270s Gen8 Base 4U Right Half Width Tray, SL270s Gen8 SE 4U Left Tray, SL270s Gen8 SE 4U Right Tray

HPE ProLiant XL Series: XL170r Gen9, XL190r Gen9, XL230a Gen9 Compute Tray, XL230a Gen9 Compute Tray (12G), XL230a Gen9 Compute Tray (6G), XL230a Gen9 NHPE Compute Tray (12G)

HPE SimpliVity 380 Gen9 Node

HPE StoreEasy 1850, 3850 Gateway Single Node

Contact us if you have any question about this product to verify this model’s compatibility with your current server or storage array.
