HPE 777747-001 1.2TB 10kRPM 2.5in QR SAS-6G Enterprise G4-G7 HDD

HPE 777747-001 1.2TB 10000RPM 2.5inch Small Form Factor Dual-Port Quick-Release SAS-6Gbps Enterprise Hard Drive for ProLiant Generation1 to Generation7 Servers (30 Days Warranty)

HPE Server Enterprise Hard Drives offer the highest level of performance and reliability for your most demanding application workloads. Enterprise drives help you improve server response times, power more transactions per second and accelerate data transfer (I/O) speeds. Drives are backed by over 3.35 million hours of the industry's most rigorous testing and qualification program ensuring customer's reliable and rugged drives.

Serial Attached SCSI (SAS) is the logical evolution of SCSI including its long-established software advantage and the serial physical connection interface. With enterprise storage requirements escalating and becoming more complex factors such as larger capacity greater density security scalability and accessibility are more critical than ever. Enterprise data centers must be online all the time fulfill requests from numerous users simultaneously allow for constant growth and expansion and be maintained while in operation. Serial Attached SCSI (SAS) meets all these demands while providing the highest performance.

The HPE 777747-001 model internal enterprise hard drive has a 2.5 inch form factor and a 6 Gbps external data transfer rate. It has a spindle speed of up to 10000 RPM and a 1.2 TB capacity.This Small Form Factor Dual Port Quick Release Hard drive uses a SAS- 6Gbps (serial attache SCSI) interface and has 30 Days Warranty.

Specifications

Brand: HPE
MPN: 777747-001

General

Device Type: Hard Drive - Hot-Swap
Capacity: 1.2 TB
Interface: SAS 6Gbps
Form Factor: 2.5 inch SFF
Buffer: 64 MB
Features: Dual-Port, Quick-Release
Bundled with: HPE Standard Carrier

Performance

Spindle Speed: 10000 RPM
External Data Transfer Rate: 600 MBps

Expansion & Connectivity

Interfaces: 1 x Serial Attached SCSI 2
Compatible Bays: 1 x hot-swap - 2.5 inch SFF

Product Dimensions

Height: 0.63 inch (1.60 cm)
Width: 3.10 inch (7.87 cm)
Depth: 5.45 inch (13.84 cm)

Environmental Parameters

Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F

Compatibility Information

HPE ProLiant BL Series: BL20p (G4) BL45p (G2) BL460c (G6 G7) BL465c (G1 G5 G6 G7) BL480c (BL620c G7)BL680c (G5 G6 G7) BL685c (G6 G7)

HPE ProLiant DL Series: DL120 (G6 G7) DL160 (G6 G7) DL160se (G6 G7) DL165 (G6 G7) DL170e (G6 G7) DL170h (G6 G7) DL180 (G6 G7) DL320 (G6 G7) DL360 (G4p G5 G6 G7) DL365 (G1 G5 G6 G7)DL370 (G6 G7) DL380 (G4 G5 G6 G7) DL385 (G1 G2 G3 G4 G5/G5p G6 G7) DL580 (G3 G4 G5 G6 G7) DL585 (G2 G3 G4 G6 G7) DL785 (G6)

HPE ProLiant ML Series: ML110 (G7) ML350 (G5 G6 G7) ML370 (G5 G6 G7) ML570 (G3 G4 G5)

HPE ProLiant SL Series: SL390s (G6 G7)

HPE ProLiant WS Series: WS460c (G6 G7)

Please contact with us if you have any question or to know the compatibility of this with your current server or storage array.
