HPE 804642-X21 200GB 3.5in DS SATA-6G SCC Write Intensive G9 G10 SSD

HPE 804642-X21 200GB 3.5inch Large Form Factor Digitally Signed Firmware SATA-6Gbps Smart Carrier Converter Write Intensive Solid State Drive for ProLiant Gen9 Gen10 Servers (Refurbished - Grade A with 30 Days Warranty)

HPE Solid State Drives (SSDs) deliver exceptional performance and endurance while reducing power consumption for customers with applications requiring high random read and write IOPs performance. These drives deliver higher performance, better latency, and more power-efficient solutions when compared with traditional rotating media.

HPE Server Write Intensive (WI) Solid State Drives (SSDs) deliver high performance and endurance for customers with applications requiring a balance of write IOPS performance. HPE (WI) SSDs typically have an endurance of >=10 drive writes per day (DWPD). All HPE SSDs are backed by over 3.35 million hours of testing and qualification ensuring reliable, high-performing drives. The self-describing icons on the HPE Smart Carrier take the guesswork out of a drive’s status, and a “do not remove” button prevents data loss from human error. You can also monitor the lifespan of your SSD with HPE SmartSSD Wear Gauge compatibility in management tools, allowing you to determine if any drives are at risk of failure.

HPE SSDs offer High Performance, Exceptional Reliability, and Efficiency for Faster Business Results
Ideal for big data analytics, cloud computing, active archiving, database applications, and data warehousing.
Achieve higher IOPS to enhance the performance of your data center.
Maintain data accuracy with full data-path error detection.
Choose from a broad portfolio of enhanced solutions in capacities up to 15.3 TB and growing.
12 Gb/s SAS, 6 Gb/s SATA, and NVMe.

Digitally Signed Firmware: Prevent unauthorized access to your data with the expansion of integrated HPE Digitally Signed Firmware (DS) on new drives; providing the security and assurance that drive firmware comes from a trusted source and protects against malicious attacks.

Smart Carriers
HPE Hard Drives with smart carriers are designed to provide an interface to communicate critical status and management information. System status LED icons and a spinning activity ring reflecting the data-writing process notify users of the current system status. A blue LED located behind the handle can be activated remotely to guide users to a specific drive tray, while a do-not-remove icon positioned on the tray's eject button lights up to warn users when the removal of the drive would cause data loss.

The HPE 804642-X21 Write Intensive Solid State Drive has a 3.5 inch form factor and a 6 Gbps data transfer rate. It has a 200 GB capacity. This Large Form Factor Digitally Signed Firmware Solid State Drive uses a SATA-6Gbps interface and has 30 Days Warranty.

Specification

Brand: HPE
MPN: 804642-X21

Option Part Number: 804642-X21
Spare Part Number: 805386-001
Model Number: MK0200GEYKC
Assembly Number: 804638-001

General

Device Type: Solid State Drive - Hot-Swap
Capacity: 200 GB
Form Factor: 3.5 inch LFF
Interface: SATA-6Gbps
Carrier Type: Smart Carrier Converter (SCC)
Workload Type: Write Intensive
Features: Digitally Signed Firmware (DS), Power Loss Protection (PLP)
Plug Type: Hot Pluggable
Bundled With: Smart Carrier Converter
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Height: 15 mm

Performance

Endurance DWPD: 10
Drive Transfer Rate: 600 MBps (external)
MAX Seq. Reads Throughput (MiB/s): 540
MAX Seq. Writes Throughput (MiB/s): 300
Random Read Average Latency uSec (4KiB,Q1): 110
Random Write Average Latency uSec (4KiB,Q1): 35
Random Read IOPS (4KiB, Q=16): 64500
Random Write IOPS (4KiB, Q=16): 42000
Max Random Read IOPS (4KiB): 72000@Q32
Max Random Write IOPS (4KiB): 42000@Q4
4KiB Random 70% Read / 30% Write, Queue 32 Performance (IOPS) VI-1: 54000
4KiB Random 50% Read / 50% Write, Queue 32 Performance (IOPS) VI-2: 50000

Expansion & Connectivity

Interfaces: 1 x SATA 6 Gb/s
Compatible Bay: 3.5" LFF

Power Consumption

Idle Time: 1.03 Watt
Random Read: 2.02 Watt
Random Write: 2.02 Watt
Sequential Read: 2.85 Watt
Sequential Write: 4.36 Watt
Random Read/Write: 2.02 Watt
Power MAX: 4.36 Watt

Compatibility Information

Designed For

HPE ProLiant BL Series: BL420c (Gen8 Gen9) BL460c (Gen8 Gen9) BL465c (Gen8 Gen9)

HPE ProLiant DL Series: DL20 (Gen9) DL60 (Gen9) DL80 (Gen9) DL120 (Gen8 Gen9) DL160 (Gen8 Gen9) DL180 (Gen8 Gen9) DL320e (Gen8 Gen9) DL360e (Gen8 Gen9) DL360p (Gen8 Gen9) DL380e (Gen8 Gen9) DL380p (Gen8 Gen9) DL388 (Gen9)

HPE ProLiant ML Series: ML110 (Gen8 Gen9) ML150 (Gen8 Gen9) ML310e (Gen8 Gen9) ML350 (Gen8 Gen9) ML350e (Gen8 Gen9)

HPE ProLiant SL Series: SL200t (Gen8 Gen9) SL230s (Gen8 Gen9) SL250s (Gen8 Gen9) SL2500 SL4550 (Gen8 Gen9) SL4545 (Gen8 Gen9) SL454x

HPE Storage Arrays: D3600 D3700

HPE StoreEasy: 1430 1440 1530 1540 1630 1640

Contact us with any questions or to verify this model’s compatibility with your current server or storage array.
