HPE MSA C8S62A 1TB 7200RPM 2.5in Dual Port SAS-6G Midline HDD

HPE C8S62A 1TB 7200RPM 2.5inch Small Form Factor Dual Port SAS-6Gbps Hot-Swap Midline Hard Drive for Modular Storage Array 1040/2040 SAN Storage (Brand New with 3 Years Warranty)

HPE Server Midline Hard Drives deliver the highest capacity, performance and reliability to your datacenter applications. Midline hard drives allow you to store more data without sacrificing performance or reliability; they are ideal to store all your bulk storage requirements. HPE Server Midline Hard Drives are available in both 3.5-inch Large Form Factor (LFF) and 2.5-inch Small Form Factor (SFF) and ship with a standard one-year warranty. All HPE hard drives pass a rigorous qualification process, which certify that every drive is proven to perform in your HPE ProLiant Server environments. Before final certification, all HPE Server Midline Hard Drives are optimized for compatibility and functionality, including support of SMART and HPE Systems Insight Manager.

Designed and Engineered to Provide High Capacity and Reliable Secure Storage
HPE Server Midline Hard Drives are ideal for the growing volume of digital content, bulk data storage, cloud and web infrastructure environments.
Broad portfolio of optimized solutions provide up to 12 TB of storage, and growing in a single device.
Rotational Vibration Sensors deliver enhanced rotational vibration tolerance that provides enterprise class reliability in midline drives.
Available in 2.5-inch Small Form Factor (SFF) and 3.5-inch Large Form Factor (LFF) in a wide variety of capacity points.

Serial Attached SCSI (SAS) is the logical evolution of SCSI including its long-established software advantage and the serial physical connection interface. With enterprise storage requirements escalating and becoming more complex factors such as larger capacity greater density security scalability and accessibility are more critical than ever. Enterprise data centers must be online all the time fulfill requests from numerous users simultaneously allow for constant growth and expansion and be maintained while in operation. Serial Attached SCSI (SAS) meets all these demands while providing the highest performance.

The HPE C8S62A Midline Hard Drive has a 2.5 inch form factor and a 6Gbps external data transfer rate. It has a spindle speed of up to 7200 RPM and a 1 TB capacity. This Small Form Factor Dual Port Hard Drive uses a SAS-6Gbps interface and comes with 3 Years Warranty.

Specifications

Brand: HPE
MPN: C8S62A

Option Part Number: C8S62A
Spare Part Number: 730706-001
Model Number: MM1000FBFVR
Model Number: MM1000FECVH
Assembly Number: 605832-002
Assembly Number: 757387-001

General

Device Type: Hard Drive - Hot-Swap
Capacity: 1 TB
Form Factor: 2.5 inch SFF
Interface: SAS 6 Gbps
Carrier Type: Standard Carrier
Plug Type: Hot Plug
Bytes per Sector: 512
Workload Type: Midline
Bundled with: HPE Standard Carrier

Performance

Drive Transfer Rate: 6 Gb/sec (external)
Spindle Speed: 7200 RPM
Average Seek Time: 8.2 ms
Max Seek Time: 17.55 ms
Track-to-Track Seek Time: 0.5 ms

Expansion & Connectivity

Compatible Bay: 2.5" SFF
Interfaces: 1 x SAS 6Gb/s

Dimensions

Width: 3.10 inch
Depth: 5.40 inch
Height: 0.63 inch

Environmental Parameters

Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F

Compatibility Information

Designed for

HPE Modular Smart Array: 1040 Dual Controller SFF Bundle, 1040 Dual Controller SFF Storage, 2040 10Gb iSCSI Dual Controller SFF Bundle, 2040 Dual Controller SFF Bundle, 2040 FC Dual Controller SFF Bundle, 2040 SAN Dual Controller SFF Bundle, 2040 SAN Dual Controller SFF Bundle Performance Tier, 2040 SAN Dual Controller SFF Storage, 2040 SAN w/o SFP SFF Bundle, 2040 SAS Dual Controller SFF Bundle, 2040 SAS Dual Controller SFF Bundle Performance Tier, 2040 SAS Dual Controller SFF Storage, 2040 SFF Chassis, 2040 SFF DC-power Chassis, P2000 2.5-in Drive Bay Chassis, P2000 G3 10GbE iSCSI Dual Controller SFF Array System, P2000 G3 FC Dual Controller SFF Modular Smart Array System, P2000 G3 FC MSA Dual Controller Virtualization SAN Starter Kit, P2000 G3 FC/iSCSI Dual Combo Controller SFF Modular Smart Array System, P2000 G3 iSCSI Dual Controller SFF Array System, P2000 G3 iSCSI Dual Controller SFF Bundle, P2000 G3 SAS Dual Controller SFF Array System

HPE P2000 DC-power SFF Chassis, P2000 G3 FC Dual Controller, P2000 G3 iSCSI Dual Controller

Contact us if you have any question about this product to verify the compatibility of this model with your current server or storage array.
