HPE P49046-H21 800GB 2.5in DS SAS-12G SC Mixed Use G9 G10 SSD

HPE P49046-H21 800GB 2.5inch Small Form Factor Digitally Signed Firmware SAS-12Gbps Smart Carrier Mixed Use Solid State Drive for ProLiant Gen9 Gen10 Servers (Brand New with 3 Years Warranty)

HPE Servers Mixed Use (MU) Solid State Drives (SSDs) deliver high performance and endurance for applications requiring high random read and write IOPS performance. HPE (MU) SSDs are backed by over 3.35 million hours of testing and qualification ensuring reliable, high-performing drives.
HPE Value SAS SSDs offer a significant performance boost over SATA SSDs with roughly twice the IOPS of SATA SSDs, enabling you to improve transactional database workloads with affordable Value SAS SSDs. HPE Digitally Signed Firmware prevents unauthorized access to your data by providing the assurance that firmware comes from a trusted source. Icons on the HPE Smart Carrier take the guesswork out of a drive’s status, and a inch do not remove inch button prevents data loss from human error. You can also monitor the lifespan of your SSD with HPE SmartSSD Wear Gauge, allowing you to determine if any drives are at risk of failure.

High Performance, Exceptional Reliability, and Efficiency for Faster Business Results
HPE solid-state drives are ideal for big data analytics, cloud computing, active archiving, database applications, and data warehousing.
Achieve higher IOPS to enhance the performance of your data center.
Maintain data accuracy with full data-path error detection.
Choose from a broad portfolio of enhanced solutions in a wide variety of capacities.
12 Gb/s SAS, 6 Gb/s SATA, and NVMe.

Value SAS SSDs Offer Twice the IOPS of SATA SSDs, Significantly Improving Workload Performance
HPE Value SAS solid-state drives (SSDs) support 12 Gbs, versus SATA SSDs at 6 Gbs.
Optimized for enterprise application workloads, HPE Value SAS SSDs allow you to do more work with fewer servers by improving and consolidating transactional database workloads.
HPE Value SAS SSDs allow you to reduce operating costs for storing, powering and maintaining servers, as well as reducing your data center footprint.
Available in a variety of storage capacities, HPE Value SAS SSDs are the perfect choice for supporting read-intensive and mixed-use applications.

HPE Multi Vendor SSDs Offer Longer SKU Lifecycles and Immediate Availability on SATA SSDs
HPE enhanced its extensive SSD portfolio with a Multi Vendor SSD SKU offering that allows for extended SKU lifecycles, immediately available supply and preferably priced SATA SSDs.
HPE Multi Vendor SSD offering ensures the SATA SSD selected, delivers the minimum level of performance published, or better.

Serial Attached SCSI (SAS) is the logical evolution of SCSI including its long-established software advantage and the serial physical connection interface. With enterprise storage requirements escalating and becoming more complex factors such as larger capacity greater density security scalability and accessibility are more critical than ever. Enterprise data centers must be online all the time fulfill requests from numerous users simultaneously allow for constant growth and expansion and be maintained while in operation. Serial Attached SCSI (SAS) meets all these demands while providing the highest performance.

Smart Carriers
HPE Hard Drives with smart carriers are designed to provide an interface to communicate critical status and management information. System status LED icons and a spinning activity ring reflecting the data-writing process notify users of the current system status. A blue LED located behind the handle can be activated remotely to guide users to a specific drive tray, while a do-not-remove icon positioned on the tray's eject button lights up to warn users when the removal of the drive would cause data loss.

Digitally Signed Firmware: Prevent unauthorized access to your data with the expansion of integrated HPE Digitally Signed Firmware (DS) on new drives; providing the security and assurance that drive firmware comes from a trusted source and protects against malicious attacks.

The HPE P49046-H21 Mixed Use Solid State Drive has a 2.5 inch form factor and a 12 Gbps external data transfer rate. It has a 800 GB capacity. This Small Form Factor Digitally Signed Firmware (DS) solid state drive uses a SAS-12Gbps interface and comes with 3 Years Warranty.

Specifications

Brand: HPE
MPN: P49046-H21

Option Part Number: P49046-H21
Spare Part Number: P49744-001

General

Device Type: Solid State Drive - Hot-Swap
Capacity: 800 GB
Form Factor: 2.5 inch SFF
Interface: SAS 12Gbps
Plug Type: Hot Pluggable
NAND Flash Memory Type: Triple-level cell (TLC)
Carrier Type: Smart Carrier (SC)
Workload Type: Mixed Use
Features: Dual Port, Digitally Signed Firmware
Bundled with: HPE Smart Carrier
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Height: 0.6 inch (15 mm)

Performance

30 Days Writes: 4380
Endurance DWPD (Drive Writes Per Day): 3
Drive Transfer Rate: 12 Gb/sec (external)
MAX Seq Reads Throughput (MiB/s): 1080
Max Seq Writes Throughput (MiB/s): 1000
Random Read Avg. Latency uSec (4KiB,Q1): 165
Random Write Avg. Latency uSec (4KiB,Q1): 95
Random Read IOPS (4KiB, Q=16): 113000
Random Write IOPS (4KiB, Q=16): 100000
Max Random Read IOPS (4KiB): 174000@Q64
Max Random Write IOPS (4KiB): 100000@Q16

Expansion & Connectivity

Interfaces: 1 x SAS 12 Gb/s
Compatible Bay: 2.5" SFF

Power Consumption

Idle Time: 3.89 Watt
Random Read: 6.47 Watt
Random Write: 6.47 Watt
Sequential Read: 8.28 Watt
Sequential Write: 8.56 Watt
Random Read/Write: 6.47 Watt
Maximum: 8.56 Watt

Compatibility Information

Designed for

HPE ProLiant DL Series: DL360 Gen10 (2.5inch), DL360 Gen10 32TB Performance Server for Cohesity DataPlatform (2.5inch), DL360 Gen10 77TB Performance Server for Cohesity DataPlatform (2.5inch), DL360 Gen10 All Flash Server for Datera (2.5inch), DL360 Gen10 All Flash Server for Weka (2.5inch), DL360 Gen10 Compute Server for Cohesity DataPlatform (2.5inch), DL360 Gen10 Entry (2.5inch), DL360 Gen10 for SAP HANA Compute Block (2.5inch), DL360 Gen10 High Performance (2.5inch), DL360 Gen10 Low (2.5inch), DL360 Gen10 Network Choice (2.5inch), DL360 Gen10 Network Choice for SAP HANA Compute Block (2.5inch), DL360 Gen10 Performance (2.5inch), DL360 Gen10 Performance for Cohesity DataPlatform (2.5inch), DL360 Gen10 Plus (2.5inch), DL360 Gen10 Plus for Weka Base Tracking (2.5inch), DL360 Gen10 Plus Network Choice (2.5inch), DL360 Gen10 Premium (2.5inch), DL360 Gen10 Remote Office Branch Office Server for Cohesity DataPlatform (2.5inch), DL360 Gen10 Server for CTERA (2.5inch), DL360 Gen10 SMB (2.5inch), DL360 Gen10 SMB Network Choice (2.5inch), DL360 Gen10 Solution (2.5inch), DL360 Gen10 Special Server (2.5inch), DL380 Gen10 48TB Server for Cohesity DataPlatform (2.5inch), DL380 Gen10 96TB Server for Cohesity DataPlatform (2.5inch), DL380 Gen10 All Flash Server for Datera (2.5inch), DL380 Gen10 Entry (2.5inch), DL380 Gen10 Entry SMB (2.5inch), DL380 Gen10 for Cohesity DataPlatform (2.5inch), DL380 Gen10 for SAP HANA Compute Block (2.5inch), DL380 Gen10 High Performance (2.5inch), DL380 Gen10 Hybrid Server for Datera (2.5inch), DL380 Gen10 Network Choice (2.5inch), DL380 Gen10 Network Choice for CTERA (2.5inch), DL380 Gen10 Network Choice for SAP HANA Compute Block (2.5inch), DL380 Gen10 NVMe All Flash Server for Datera (2.5inch), DL380 Gen10 Performance (2.5inch), DL380 Gen10 Plus (2.5inch), DL380 Gen10 Plus Network Choice (2.5inch), DL380 Gen10 Server for CTERA (2.5inch), DL380 Gen10 SMB (2.5inch), DL380 Gen10 SMB Networking Choice (2.5inch), DL380 Gen10 Solution (2.5inch), DL380 Gen10 Special (2.5inch), DL380 Gen10 with Microsoft Azure Stack Hub All Flash Node (2.5inch)

Contact us with any questions or to verify this model’s compatibility with your current server or storage array.
